Backyard Discovery 2105324 - Page 22

STEP 5
LAG SCREW WH BLK
1/4x3
(x4)
H100792
WASHER LOCK
EXT BLK
6x15
(x4)
H100405
WASHER LOCK
EXT BLK
8x19
(x8)
H100198
CORBEL - W4L14996
1 3/8"x5 1/4"x45 5/8" (36x134x1160)
D06
(x3)
COMPLETE THIS STEP TWICE
ˣ˟ˤ ʹɮˡʺ
ɟǢËrNJ˚˥ɮˠˤ
˦˨ˡ ʹɮˡʺ
ĵµǢNNJrɟ˚ˢ˃
^˟˥ ʹɮˠʺ
NŷNJDrĵ
CA01
(x1)
CORBEL - W2A02879
1 7/16"x5 3/8"x46 1/16" (36x136x1170)
N˟ˠ ʹɮˠʺ
NŷNJDrĵ
ˢ˦˨ ʹɮˣʺ
ǻ˚ŗȕǻ˚ˤˀˠ˥˃
ˠ˨˧ ʹɮˣʺ
ɟǢËrNJ˚˧ɮˠ˨
ˠ˨ˤ ʹɮˣʺ
Dŷĵǻ˚ˡ˚ˢˀˣ
T-NUT BLK
5/16
(x8)
H100379
BOLT WH BLK
5/16x2-3/4
(x8)
H100195
