Backyard Discovery 2105324 - Page 24

STEP 7
^˟ˢ ʹɮˡʺ
ǻŷƻNJÝĵ
^˟ˣ ʹɮˡʺ
NŷNJDrĵ
TOP RAIL - W4L14994
1 3/8"x5 1/4"x57" (36x134x1448)
D03
(x2)
CORBEL - W4L14997
1 3/8"x5 1/4"x35 7/8" (36x134x910)
D04
(x2)
LAG SCREW WH BLK
1/4x3
(x2)
H100792
WASHER LOCK
EXT BLK
6x15
(x2)
H100405
WASHER LOCK
EXT BLK
8x19
(x20)
H100198
ˣ˟ˤ  ʹɮˡʺ
ɟǢËrNJ˚˥ɮˠˤ
˦˨ˡ ʹɮˡʺ
ĵµǢNNJrɟ˚ˢ˃
ˢ˦˨ ʹɮˡ˟ʺ
ǻ˚ŗȕǻ˚ˤˀˠ˥˃
ˠ˨˧ ʹɮˡ˟ʺ
ɟǢËrNJ˚˧ɮˠ˨
ˠ˨ˤ ʹɮˠˡʺ
Dŷĵǻ˚ˡ˚ˢˀˣ
ˤˠˢ ʹɮ˧ʺ
Dŷĵǻ˚ˣˠˀˣ˃
T-NUT BLK
5/16
(x20)
H100379
BOLT WH BLK
5/16x2-3/4
(x12)
H100195
BOLT WH BLK
5/16x4-1/4
(x8)
H100513
24
