STEP 14
29 GA STEEL SHEETING
(x2)
A4M01124
29 GA STEEL SHEETING
(x1)
A4M01253
MAKE SURE YOUR ROOF PANEL IS
SQUARE BEFORE MOVING ON.
5/16"
[8mm]
SCREW WOODGRIP
10x1 1/4
(x12)
H100760
NOTE RIB OVERLAP
˦˥˟ ʹɮˠˡʺ
ǢNNJrɟ˚ˠˠˀˣ˃
NOTE THRU HOLES
ˡˤˢ ʹɮˠʺ
ˡ˨µǢǻrrĵǢËrrǻÝŗµ
ˠˡˣ ʹɮˡʺ
ˡ˨µǢǻrrĵǢËrrǻÝŗµ
1/2"
[12mm]
HOLD SHEETING INSIDE OF FRAME
