STEP 31
ğ˟˨ ʹɮˠʺ
NJÝ^µrNƻǢǻÝ®®rŗrNJ
ğˠ˟ ʹɮˠʺ
NJÝ^µrNƻǢǻÝ®®rŗrNJ
ğˠ˟ ʹɮˠʺ
NJÝ^µrNƻǢǻÝ®®rŗrNJ
ğ˟˨ ʹɮˠʺ
NJÝ^µrNƻǢǻÝ®®rŗrNJ
˧ˢˢ ʹɮˡ˟ʺ
ǢNNJrɟ˚ˢˀˣ˃
ˢ˨˧ ʹɮˠʺ
NJÝ^µrNƻƻNJŷǻrNǻŷNJ
ˢ˨˧ ʹɮˠʺ
NJÝ^µrNƻƻNJŷǻrNǻŷNJ
RIDGE CAP PROTECTOR
(x2)
A6P00398
RIDGE CAP STIFFENER - W4L15002
1"x2 3/8"x77 5/8" (24x60x1973)
J09
(x2)
RIDGE CAP STIFFENER - W4L15003
1"x2 3/8"x89 1/2" (24x60x2273)
J10
(x2)
SCREW
WOODGRIP
10x3/4
(x20)
H100833
ŗŷǻrʲ
REMOVE SPACERS AS
SHOWN BEFORE INSTALLING.
ASSEMBLE BY ALIGNING THE HOLES
ON EACH RIDGE CAP TO THE HOLES
IN THE RIDGE CAP SPLICE.
FINAL LENGTH IS 13'-11 3/8" [4250mm]
ŗŷǻrʲ
RIDGE CAP MUST BE LIFTED
FROM THE MIDDLE TO
PREVENT DAMAGE BEFORE
INSTALLATION.
