STEP 32
SCREW PWH BLK
8x3/4
(x22)
H100392
RIDGE CAP ASSEMBLY FROM PREVIOUS STEP
RIDGE CAP ASSEMBLY
FROM PREVIOUS STEP
RIDGE CAP ASSEMBLY HAS BEEN
DESIGNED FOR SAFE INSTALLATION
FROM A LADDER AND NO ROOF ACCESS
IS REQUIRED NOR RECOMMENDED.
USING AN ADULT HELPER,
SLIDE RIDGE CAP ASSEMBLY
CAREFULLY ACROSS THE
ROOF RIDGE UNTIL BOTH
ENDS SIT INSIDE RAFTERS
AS SHOWN.
FOR PROPER INSTALLATION, USE AN
ADULT HELPER TO KEEP DOWNWARD
PRESSURE ON THE RIDGE CAP DURING
SCREW INSTALLATION.
ŗŷǻrʲ
ˢ˨ˡ
ʹɮˡˡʺ
ǢNNJrɟ˚ˢˀˣ˃
INSTALL SCREWS THRU PILOT HOLES
IN ROOF PANELS INTO RIDGE CAP
STIFFENER BOARDS.
49
