STEP 10 - ROOF SUPPORT ASSEMBLY
ROOF SUPPORT-W4L16928
1"x3 3/8"x75 3/16" (24x86x1909)
H19
(
4
)
REPEAT ON ON OPPOSITE END OF ROOF SUPPORT BOARD
INSERT T-NUTS FIRST
29
