Backyard Discovery 2106536D - Page 35

11
STEP 16 - 14FT ROOF PANEL ASSEMBLY
RAFTER- W4L16288
1 3/8"x3 3/8"x63 7/8" (36x86x1622)
E02
(2)
RAFTER- W4L16290
1 3/8"x3 3/8"x63 7/8" (36x86x1622)
E11
(1)
RAFTER- W4L16286
1 3/8"x3 3/8"x20 7/16" (36x86x519)
E03
(1)
RAFTER - W4L16287
1 3/8"x3 3/8"x20 7/16" (36x86x519)
E06
(1)
RAFTER- W4L16285
1 3/8"x3 3/8"x44"
(36x86x1117)
E04
(1)
RAFTER- W4L16284
1 3/8"x3 3/8"x44" (36x86x1117)
E01
(1)
35
