(4
)
STEP 17A - 14FT ROOF PANEL ASSEMBLY
Q01
(
2)
ROOF JOIST-W4L16294
1"x
4 7/16"x84 9/16" (24x112x2148)
TIP:
• RAFTERS MAY NEED TO BE LOOSENED TO ATTACH Q01 TO H01/H09
36
