STEP 25A - 10FT ROOF PANEL ASSEMBLY
Q02
ROOF JOIST-W4L16307
1
"x4
7/16"
x6
1 1/2" (24x112x1562)
(
2)
TIP:
• RAFTERS MAY NEED TO BE LOOSENED TO ATTACH Q02 TO H12/H10
47
