Backyard Discovery 37113 - Page 13

Parts Identification
Wood Components
(NOT TO SCALE)
(2) M2 - BENCH SEAT - W103420
5/8"x3 3/8"x24 3/8" (16mmx86mmx618mm)
(1) N2 - ROOF CAP - W102465
5/8"x2"x5 7/8" (16mmx50mmx150mm)
(1) N3 - SERVING SHELF - W103341
5/8"x2 1/4"x19 1/8" (16mmx57mmx485mm)
(10) N4 - TIE STRAP - W102424
5/8"x2"x3 1/8" (16mmx50mmx80mm)
(1) N5 - DORMER BASE BOARD - W102409
5/8"x2 3/8"x36 5/8" (16mmx60mmx930mm)
(2) N1 - WALL CLEAT - W103334
5/8"x2 3/8"x47 1/8" (16mmx60mmx1197mm)
(1) N8 - WALL CLEAT - W103335
5/8"x2 3/8"x45 7/8" (16mmx60mmx1165mm)
(2) N9 - WALL CLEAT - W103421
5/8"x2 3/8"x13 3/8" (16mmx60mmx340mm)
(1) O1 - ROOF CAP - W103416
5/8"x1 3/8"x36 5/8" (16mmx34mmx1129mm)
(1) O2 - ROOF CAP - W103414
5/8"x1 3/8"x5 7/8" (16mmx34mmx150mm)
(1) P1 - POST - W103346
1 3/8"x1 3/8"x44" (36mmx36mmx1118mm)
(1) P2 - POST - W103406
1 3/8"x1 3/8"x44" (36mmx36mmx1118mm)
(1) P3 - POST - W103407
1 3/8"x1 3/8"x44" (36mmx36mmx1118mm)
(1) P4 - POST - W103347
1 3/8"x1 3/8"x44" (36mmx36mmx1118mm)
(2) M1 - CHIMNEY SIDE - W102464
5/8"x3 1/8"x5 1/8" (16mmx80mmx130mm)
(1) N6 - ROOF CAP - W103417
5/8"x2"x44 1/2" (16mmx50mmx1129mm)
