Parts Identification
Wood Components
(NOT TO SCALE)
(2) WP2 - SIDE PANEL - W102387
(1) T1 - COUNTER TOP WALL SUPPORT - W103337
1"x1 3/8"x14" (24mmx34mmx356mm)
(1) T2 - TIE STRAP - W103338
1"x1 3/8"x47 1/8" (24mmx34mmx1197mm)
(1) T4 - TIE STRAP - W103339
1"x1 3/8"x45 1/4" (24mmx34mmx1149mm)
(1) WP6 - RIGHT FRONT PANEL - W103423
(1) WP5 - LEFT FRONT PANEL - W103424
(2) WP4 - WINDOW PANEL - W103232
(1) DP1 - DOOR ASSEMBLY - W103326
(1) WP3 - MIDDLE SIDE PANEL - W103333
(1) WP10 - SHUTTER ASSEMBLY - W103342
(1) WP8 - RIGHT PANEL - W103345
