Backyard Discovery 37113 - Page 46

STEP 28
M1 - CHIMNEY SIDE - W102464
5/8"x3 1/8"x5 1/8" (16x80x130)
(2)
SCREW PFH
8x1-1/2
(4)
M1
L1
L1
L1
WJ
G2
SCREW PFH 8x1-1/2
(4 PLCS)
SCREW PFH 8x1-3/4
(4 PLCS)
SCREW PFH
8x1-3/4
(4)
L1 - CHIMNEY FRONT PANEL - W103415
5/8"x4 3/8"x5 1/8" (16x112x130)
(2)
G2 - CHIMNEY TOP - W103422
1"x5 1/4"x5 1/4" (24x134x134)
(1)
WJ - CHIMNEY CAP - A100394
(1)
