1"
STEP 29
CHIMNEY ATTACHMENT
ATTACH FROM INSIDE
SCREW PFH
8x1-1/4
(2)
SCREW PFH 8x1-1/4
(2 PLCS)
(1) CHIMNEY ASSEMBLY
5/16"
SET CHIMNEY ON ROOF AGAINST PREVIOUSLY INSTALLED ROOF CAP BOARDS. MARK AROUND
OUTSIDE OF CHIMNEY. LOCATE DRILLING MARK AS SHOWN. PILOT DRILL USING 1/8" DRILL BIT,
VERTICAL TO THE GROUND. USING (2) 8x1-1/4" SCREWS ATTACH CHIMNEY TO ROOF ON BOTH
SIDES OF ROOF.
