STEP 27:
REAR
LEFT
FRONT
RIGHT
SCREW PFH 8x1 3/4
(8 PLCS)
SCREW PFH
8x1 3/4
(8)
RP1
RP1
RP1 - PEAK ROOF PANEL - W2A01767
1 3/8"x7 5/8"x44 5/8" (35x195x1134)
(2)
