STEP 28:
REAR
LEFT
FRONT
RIGHT
SCREW PFH 8x1 3/4
(8 PLCS)
SCREW PFH
8x1 3/4
(8)
(2)
RP2
RP2
RP2 - MIDDLE ROOF PANEL - W2A01768
1 3/8"x9 3/4"x44 5/8" (35x248x1134)
