Phase 2
REFERENCE
IMPORTANT: BRACKET CONFIGURATION ASSEMBLY & PLACEMENT.
2 HOLES
3 HOLES
1 HOLE
CONFIGURATION 'A' DIAGRAM
CONFIGURATION 'B' DIAGRAM
CONFIGURATION 'A'
CONFIGURATION 'B'
NOTE ALIGNMENT MARKINGS
PAY CLOSE ATTENTION TO THE ALIGNMENT MARKINGS ON
EACH SLIDE SECTION. THE MARKINGS WILL AID YOU IN
POSITIONING THE METAL SLIDE BRACKETS CORRECTLY.
NOTE:
