Backyard Discovery ASHLAND - Page 28

TIP:
FOR EASE OF ASSEMBLY ATTACH
W01 USING THE 1-3/4" SCREWS
PRIOR TO ATTACHING THE
BRACKETS.
STEP 12
392 (x2)
SCREW - 3/4"
110 (x1)
90° L-BRACKET - BLK
821 (x9)
SCREW 2-3/4"
W01 (x1)
TABLE TOP RAIL
TABLE TOP RAIL - W4L12984
2"x3"x84 1/2" (50x76x2146)
W01
(x2)
SCREW PFH BLK
8x2-3/4
(x18)
H100821
90° L-BRACKET - BLK
(x4)
A4M01110
SCREW PWH BLK
8x3/4
(x8)
H100392
REPEAT ON EACH CORNER
28
