Backyard Discovery ASHLAND - Page 32

NOTE:
CENTER D14 ON THE POST AND
CENTER SLOT ON D14 ON THE
BAR THEN ASSEMBLE AS
SHOWN.
PRESS THE ELECTRICAL CORD ASSEMBLY
INTO THE CUT OUTS ON THE D14 CORD
COVER, AS SHOWN.
STEP 16
201 (x10)
SCREW - 2 1/2"
D14
CORD COVER
J01 (x1)
CORD COVER
D14 (x1)
CORD COVER
CORD COVER - W4L12986
1"x5 1/4"x43 5/8" (24x134x1109)
D14
(x1)
CORD COVER - W4L12987
1"x2 3/8"x7 7/8" (24x60x201)
J01
(x1)
SCREW PFH BLK
8x2-1/2
(x10)
H100201
5' PERGOLA ELECTRICAL OUTLET ASSEMBLY
(x1)
A6P00265
NOTE SLOT IN D14.
265 (x1)
5' PERGOLA ELECTRICAL OUTLET ASSEMBLY
32
