Backyard Discovery ATLANTIS - Fort Assembly: Step 4; T-Nut Installation Tip

STEP 4 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
2
H100010 BOLT WH 5/16x1 1/2
2 H100011 BOLT WH 5/16x1 3/4
4 H100030 WASHER LOCK EXT 8x19
4 H100074 T-NUT 5/16
2
H100128 SCREW PWH 8x5/8
4
H100138
WASHER LOCK EXT 6x15
4 H100146 LAG SCREW WH 1/4x2
011 (x2)
BOLT - 1 3/4"
030 (x4)
WASHER - 8x19
074 (x4)
T-NUT - 5/16"
146 (x4)
LAG SCREW - 2"
138 (x4)
WASHER - 6x15
010 (x2)
BOLT - 1 1/2"
DECK BRACE - W100561
1"x2 3/8"x15 3/4" (24x60x400)
J1
(x4)
J1 (x4)
"A" REVISION TAG
(x1)
A100314
TIP:
IN
STALL T-NUTS INTO
BOARDS BEFORE ASSEMBLY
314 (x1)
"A" REVISION TAG
128 (x2)
SCREW - 5/8
36
