Backyard Discovery ATLANTIS - Fort Assembly: Step 3; T-Nut Installation Tip

STEP 3 - FORT ASSEMBLY
QTY
PART
NUMBER
DESCRIPTION
18 H100020
BOLT WH 5/16x4
8 H100027
LAG SCREW WH 5/16x2
26 H100030
WASHER LOCK EXT 8x19
18 H100074
T-NUT 5/16
020 (x4)
BOLT - 4"
030 (x26)
WASHER - 8x19
020 (x4)
BOLT - 4"
027 (x4)
LAG SCREW - 2"
020 (x2)
BOLT - 4"
020 (x8)
BOLT - 4"
074 (x18)
T-NUT - 5/16"
027 (x4)
LAG SCREW - 2"
L3 (x1)
M8 (x1)
K3 (x1)
M8 (x1)
K2 (x1)
K2 (x1)
M6 (x1)
L8 (x1)
FLOOR RAIL - W4L16267
5/8"x3 3/8"x40" (16x86x1016)
M6
(x1)
FRONT ARCH - W100564
5/8"x5 1/4"x40" (16x134x1016)
K3
(x1)
CLUB HOUSE WALL RAIL - W100569
5/8"x4 3/8"x40" (16x112x1016)
L8
(x1)
BASE BOARD - W100563
5/8"x5 1/4"x40" (16x134x1016)
K2
(x2)
WALL RAIL - W100568
5/8"x4 3/8"x40" (16x112x1016)
L3
(x1)
WALL RAIL - W100580
5/8"x3 3/8"x40" (16x86x1016)
M8
(x2)
TIP:
INSTALL
T-NUTS INTO
BOARDS BEFORE ASSEMBLY
35
