Backyard Discovery ATLANTIS - Page 4

Wood Components (Not to Scale)
TABLE SUPPORT - W100560
1"x2"x4" (24x51x102)
H4
(x2)
FLOOR SUPPORT - W100598
1"x3 3/8"x3 3/8" (24x86x86)
H5
(x4)
LEFT UPRIGHT - W4L16265
1"x3 3/8"x50 3/4" (24x86x1290)
H6
(x1)
RIGHT UPRIGHT - W4L16266
1"x3 3/8"x50 3/4" (24x86x1290)
H7
(x1)
GROUND BOARD - W4L14653
1"x3 3/8"x79 1/2" (24x86x2018)
H80
(x1)
DECK BRACE - W100561
1"x2 3/8"x15 3/4" (24x60x400)
J1
(x4)
ATTACHMENT BOARD - W4L16268
1"x3 3/8"x20 1/4" (24x86x514)
J2
(x1)
BASE BOARD - W100562
5/8"x5 1/4"x63 7/8" (16x134x1624)
K1
(x2)
BASE BOARD - W100563
5/8"x5 1/4"x40" (16x134x1016)
K2
(x2)
FRONT ARCH - W100564
5/8"x5 1/4"x40" (16x134x1016)
K3
(x1)
TABLE TOP - W100565
5/8"x5 1/4"x37" (16x134x940)
K4
(x1)
LEFT WALL RAIL - W102360
5/8"x4 3/8"x63 7/8" (16x112x1624)
L1
(x1)
RIGHT WALL RAIL - W100567
5/8"x4 3/8"x63 7/8" (16x112x1624)
L2
(x1)
Owners Manual - Parts Identification
