Backyard Discovery ATLANTIS - Fort Assembly: Step 8; T-Nut Installation Tip

STEP 8 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
1 H100012 BOLT WH 5/16x2
2
H100026
LAG SCREW WH 5/16x1 1/2
4 H100027 LAG SCREW WH 5/16x2
7 H100030
WASHER LOCK EXT 8x19
1 H100074 T-NUT 5/16
012 (x1)
BOLT - 2"
074 (x1)
T-NUT - 5/16"
027 (x4)
LAG SCREW - 2"
030 (x7)
WASHER - 8x19
M8 (x1)
M1 (x1)
M13 (x2)
M14 (x1)
WALL RAIL - W100573
5/8"x3 3/8"x63 7/8" (16x86x1624)
M1
(x1)
WALL RAIL - W100580
5/8"x3 3/8"x40" (16x86x1016)
M8
(x1)
WALL RAIL - W100585
5/8"x3 3/8"x8 1/4" (16x86x208)
M13
(x2)
WALL RAIL - W100586
5/8"x3 3/8"x6 3/4" (16x86x172)
M14
(x1)
TIP:
INSTALL T-NUTS INTO
BOARDS BEFORE ASSEMBLY
28 1/4 in
[716 mm]
026 (x2)
LAG SCREW - 1 1/2"
40
