Backyard Discovery Bay Pointe - Step 4: Lower Floor Rail Attachment

FORT ASSEMBLY
STEP 4
FLOOR RAIL - W4L13213
1"x3 3/8"x26" (24x86x660)
H2
(1)
FLOOR SUPPORT - W4L13222
1"x3 3/8"x3 3/8" (24x86x86)
H4
(2)
BOLT WH
5/16x2
(2)
H100012
BOLT WH
5/16x3 1/4
(2)
H100017
T-NUT
5/16
(4)
H100074
WASHER LOCK
EXT
8x19
(4)
H100030
GROUND RAIL - W4L13216
5/8"x3 3/8"x25 3/8" (16x86x644)
M2
(1)
030 (x2)
WASHER - 8x19
017 (x2)
BOLT - 3-1/4"
030 (x2)
WASHER - 8x19
012 (x2)
BOLT - 2"
074 (x2)
T-NUT - 5/16"
074 (x2)
T-NUT - 5/16"
M2 (x1)
H2 (x1)
H4 (x2)
23
