Backyard Discovery Bay Pointe - Fort Assembly - Mid-Level Construction; Step 5: Floor Rail and Support Attachment

FORT ASSEMBLY
STEP 5
FLOOR SUPPORT - W4L13289
15/16"x1 5/16"x17 1/4" (24x34x438)
T1
(2)
FLOOR RAIL - W4L13221
1"x3 3/8"x24 1/8" (24x86x612)
H3
(1)
"A" REVISION TAG
(1)
A100314
SCREW PFH
8x2 1/2"
(4)
H100090
SCREW PFH
8x1 3/4
(10)
H100089
SCREW PWH
8x5/8
(2)
H100128
090 (x4)
SCREW - 2 1/2"
089 (x10)
SCREW - 1 3/4"
128 (x2)
SCREW - 5/8
314 (x1)
"A" REVISION TAG
(APPROXIMATE LOCATION)
T1 (x2)
H3 (x1)
