Backyard Discovery Bay Pointe - Fort Assembly - Ladder Attachment; Step 9: Ladder Attachment to Fort

FORT ASSEMBLY
STEP 9
010 (x1)
BOLT - 1 1/2"
029 (x1)
LAG SCREW - 3"
030 (x3)
WASHER - 8x19
027 (x1)
LAG SCREW - 2"
WASHER LOCK
EXT
8x19
(3)
H100030
T-NUT
5/16
(1)
H100074
074 (x1)
T-NUT - 5/16"
BOLT WH
5/16x1-1/2
(1)
H100010
LAG SCREW WH
5/16x3
(1)
H100029
LAG SCREW WH
5/16x2
(1)
H100027
(1) LADDER ASSEMBLY
LADDER ASSEMBLY (1)
28
