Backyard Discovery Bay Pointe - Fort Assembly - Ladder Support; Step 10: Ladder Support Brackets

FORT ASSEMBLY
STEP 10
LAG SCREW WH
5/16x2
(1)
H100027
WASHER LOCK
EXT
8x19
(1)
H100030
WASHER LOCK
EXT
12x19
(2)
H100031
BOLT WH
5/16x1/2
(2)
H100115
NUT BARREL WH
5/16 x 5/8
(2)
H100004
GROUND RAIL - W4L13296
5/8"x3 3/8"x21 3/8" (16x86x542)
M6
(1)
TOP LADDER RUNG - W4L13287
5/8"x4 3/8"x16 7/8" (16x112x430)
L5
(1)
SCREW PFH
8x1 1/2
(4)
H100086
L BRACKET
2.5x38x55x55
(1)
A4M01048
030 (x1)
WASHER - 8x19
027 (x1)
LAG SCREW - 2"
004 (x2)
NUT BARREL - 5/8"
031 (x2)
WASHER - 12x19
115 (x2)
BOLT - 1/2"
048 (x1)
L BRACKET 2.5x38x55x55
086 (x4)
SCREW - 1 1/2"
L5 (x1)
M6 (x1)
29
