Wood Components (Not to Scale)
Parts Identification
UPRIGHT POST - W4L13768
3"x3"x89 1/2" (76x76x2274)
B2
(x1)
UPRIGHT POST - W4L13769
3"x3"x89 1/2" (76x76x2274)
B3
(x1)
UPRIGHT POST - W4L13770
3"x3"x89 1/2" (76x76x2274)
B4
(x1)
RAIL - W4L13761
1 3/8"x3"x51 7/8" (36x76x1318)
E1
(x1)
RAIL - W4L13755
1 3/8"x3"x51 7/8" (36x76x1318)
E2
(x1)
RAIL - W4L13762
1 3/8"x3"x51 7/8" (36x76x1318)
E3
(x1)
ANGLE BRACE - W4L13782
1 3/8"x3 3/8"x80 1/2" (36x86x2043)
E77
(x2)
GROUND BOARD - W4L13582
1"x5 1/4"x79 1/8" (24x134x2010)
G1
(x1)
WALL RAIL - W4L07153
1"x5 1/4"x48 7/8" (24x134x1243)
G2
(x1)
GROUND BOARD - W4L13784
1"x5 1/4"x79" (24x134x2006)
G50
(x1)
LEFT UPRIGHT - W4L13775
1 3/8"x3 3/8"x50 3/4" (36x86x1290)
E74
(x1)
RIGHT UPRIGHT - W4L13776
1 3/8"x3 3/8"x50 3/4" (36x86x1290)
E75
(x1)
END SUPPORT - W4L13783
1 1/2"x3 1/2"x44 1/2" (36x86x1127)
E79
(x1)
