Wood Components (Not to Scale)
Parts Identification
FLOOR SUPPORT - W4L07130
1"x3 3/8"x48 7/8" (24x86x1243)
H4
(x1)
FLOOR SUPPORT - W4L07131
1"x3 3/8"x48 7/8" (24x86x1243)
H5
(x1)
UPRIGHT - W4L13763
1"x3 3/8"x72" (24x86x1828)
H6
(x1)
UPRIGHT - W4L13764
1"x3 3/8"x72" (24x86x1828)
H7
(x1)
ROOF RAIL - W4L13765
1"x3 3/8"x83 7/8" (24x86x2132)
H8
(x2)
ROOF RAIL - W4L13766
1"x3 3/8"x50 7/8" (24x86x1291)
H9
(x2)
ROOF RAIL - W4L13767
1"x3 3/8"x48 7/8" (24x86x1243)
H10
(x1)
DECK BRACE - W4L07296
1"x3 3/8"x17 3/4" (24x86x450)
H11
(x2)
DECK BRACE - W4L13771
1"x3 3/8"x15 7/8" (24x86x402)
H12
(x4)
ARCHED RAIL - W4L13774
1"x3 3/8"x50 7/8" (24x86x1292)
H13
(x1)
LADDER RUNG - W4L13778
1"x3 3/8"x17 1/8" (24x86x434)
H81
(x4)
FLOOR SUPPORT - W4L13772
1"x3 3/8"x52 1/8" (24x86x1324)
H2
(x1)
FLOOR SUPPORT - W4L13773
1"x3 3/8"x52 1/8" (24x86x1324)
H3
(x1)
ANGLE BRACE - W4L07127
1"x3 3/8"x44 1/2" (24x86x1129)
H1
(x2)
