Wood Components (Not to Scale)
Parts Identification
FLOOR JOIST - W4L07139
1"x2 3/8"x50 1/4" (24x60x1275)
J1
(x2)
FLOOR SUPPORT - W4L06710
1"x2 3/8"x3" (24x60x76)
J2
(x4)
GROUND BOARD - W4L07122
5/8"x5 1/4"x74 1/4" (16x134x1888)
K1
(x1)
GROUND BOARD - W4L07123
5/8"x5 1/4"x89 3/8" (16x134x2270)
K2
(x1)
GROUND BOARD - W4L07124
5/8"x5 1/4"x50 1/8" (16x134x1274)
K3
(x1)
GROUND BOARD - W4L13756
5/8"x5 1/4"x23 1/8" (16x134x588)
K4
(x1)
GROUND BOARD - W4L13757
5/8"x4 3/4"x50 1/4" (16x120x1275)
K5
(x1)
ROCK WALL BOARD - W4L13758
5/8"x3 3/8"x48 7/8" (16x86x1243)
M1
(x7)
ROCK WALL BOARD - W4L13759
5/8"x3 3/8"x48 7/8" (16x86x1243)
M2
(x3)
ROCK WALL BOARD - W4L13760
5/8"x3 3/8"x48 7/8" (16x86x1243)
M3
(x3)
FLOOR BOARD - W4L07141
5/8"x3"x42 7/8" (16x76x1090)
M4
(x2)
FLOOR BOARD - W4L07142
5/8"x3 3/8"x48 7/8" (16x86x1242)
M5
(x1)
WALL RAIL - W4L07145
5/8"x3 3/8"x50 7/8" (16x86x1292)
M8
(x2)
