Owner's Manual
Wood Components (Not to Scale)
Parts Identification
WALL RAIL - W4L07146
5/8"x3 3/8"x48 7/8" (16x86x1243)
M9
(x3)
PICKET - W4L07152
5/8"x3 3/8"x21 3/8" (16x86x542)
M44
(x13)
SLIDE BRACE - W4L08748
5/8"x3 3/8"x17 1/4" (16x86x438)
M77
(x1)
CENTER SLIDE BRACE - W4L08749
5/8"x3 3/8"x17 1/4" (16x86x438)
M78
(x2)
ATTACHMENT BOARD - W4L13779
5/8"x3 3/8"x19" (16x86x482)
M102
(x1)
REAR SUPPORT - W4L13777
5/8"x3 3/8"x19" (16x86x482)
M103
(x1)
SWING BEAM 2 POSITION - W4L13780
2"x5 1/4"x68 3/4" (50x134x1745)
SB74
(x1)
SUPPORT BOARD - W4L07140
1"x1 3/8"x44 1/8" (24x34x1122)
T1
(x2)
SUPPORT BOARD - W4L07156
2"x3 3/8"x78 7/8" (50x86x2005)
W1
(x1)
SWING BEAM SUPPORT - W4L13781
2"x3 3/8"x49 3/8" (50x86x1254)
W71
(x1)
B1
(x1)
UPRIGHT POST ASSEMBLY - W2A02851
3"x3"x89 1/2" (76x76x2274)
FP1
(x2)
FLOOR PANEL - W2A02850
1 1/4"x20 3/8"x48 5/8" (32x519x1242)
To Next Page
