FORT ASSEMBLY
STEP 8
030 (x2)
WASHER - 8x19
011 (x2)
BOLT - 1 3/4"
146 (x2)
LAG SCREW - 2"
138 (x2)
WASHER - 6x15
138 (x2)
WASHER - 6x15
146 (x2)
LAG SCREW - 2"
074 (x4)
T-NUT - 5/16"
030 (x4)
WASHER - 8x19
010 (x4)
BOLT - 1 1/2"
H1 (x1)
ANGLE BRACE
H11 (x1)
DECK BRACE
H1 (x1)
ANGLE BRACE
H11 (x1)
DECK BRACE
DECK BRACE - W4L07296
1"x3 3/8"x17 3/4" (24x86x450)
H11
(x2)
ANGLE BRACE - W4L07127
1"x3 3/8"x44 1/2" (24x86x1129)
H1
(x2)
074 (x2)
T-NUT - 5/16"
H11 DECK BRACE
T-NUT SUB ASSEMBLY
T-NUT
5/16
(x6)
H100074
BOLT WH
5/16x1-1/2
(x4)
H100010
BOLT WH
5/16x1 3/4
(x2)
H100011
LAG SCREW WH
1/4x2
(x4)
H100146
WASHER LOCK
EXT
6x15
(4)
H100138
WASHER LOCK
EXT
8x19
(6)
H100030
TIP:
INSTALL T-NUTS IN WOOD FIRST
