Backyard Discovery GRAYSON PEAK - Page 33

FORT ASSEMBLY
STEP 9
E3 RAIL
E2 RAIL
E1 RAIL
074 (x3)
T-NUT - 5/16"
T-NUT SUB ASSEMBLY
027 (x2)
LAG SCREW - 2"
027 (x4)
LAG SCREW - 2"
RAIL - W4L13761
1 3/8"x3"x51 7/8" (36x76x1318)
E1
(x1)
RAIL - W4L13755
1 3/8"x3"x51 7/8" (36x76x1318)
E2
(x1)
RAIL - W4L13762
1 3/8"x3"x51 7/8" (36x76x1318)
E3
(x1)
LAG SCREW WH
5/16x2
(x6)
H100027
WASHER LOCK
EXT
8x19
(x7)
H100030
T-NUT
5/16
(x4)
H100074
E3 (x1)
RAIL
E2 (x1)
RAIL
E1 (x1)
RAIL
030 (x4)
WASHER - 8x19
030 (x3)
WASHER - 8x19
010 (x1)
BOLT - 1 1/2"
BOLT WH
5/16x1-1/2
(x1)
H100010
TIP:
INSTALL T-NUTS IN WOOD FIRST
