Backyard Discovery GRAYSON PEAK - Page 34

FORT ASSEMBLY
STEP 10
030 (x5)
WASHER - 8x19
012 (x3)
BOLT - 2"
NOTE HOLE LOCATION FOR
PROPER ORIENTATION OF
THE BOARD.
K5 (x1)
GROUND BOARD
GROUND BOARD - W4L13757
5/8"x4 3/4"x50 1/4" (16x120x1275)
K5
(x1)
WASHER LOCK
EXT
8x19
(x5)
H100030
BOLT WH
5/16x2
(x3)
H100012
026 (x2)
LAG SCREW - 1 1/2"
LAG SCREW WH
5/16x1 1/2
(x2)
H100026
34
