FORT ASSEMBLY
STEP 11
090
(x8)
SCREW - 2 1/2"
J1
(x2)
FLOOR JOIST
FLOOR JOIST - W4L07139
1"x2 3/8"x50 1/4" (24x60x1275)
J1
(x2)
J1
(x2)
FLOOR JOIST
5/8 in
[16 mm]
SCREW PFH
8x2 1/2"
(x8)
H100090
35
