FORT ASSEMBLY
STEP 15
T1
(x1)
SUPPORT BOARD
T1
(x1)
SUPPORT BOARD
089
(x10)
SCREW - 1 3/4"
FLUSH
SUPPORT BOARD - W4L07140
1"x1 3/8"x44 1/8" (24x34x1122)
T1
(x2)
SCREW PFH
8x1 3/4
(x10)
H100089
39
