FORT ASSEMBLY
STEP 14
5/8 in
[16 mm]
J2 (x1)
FLOOR SUPPORT
(4 CORNER POSTS)
089 (x2)
SCREW - 1 3/4"
J2 FLOOR SUPPORT
CORNER POST
FLOOR SUPPORT
FLOOR SUPPORT
CORNER POST
FLOOR SUPPORT - W4L06710
1"x2 3/8"x3" (24x60x76)
J2
(x4)
SCREW PFH
8x1 3/4
(x8)
H100089
FLUSH
