Backyard Discovery GRAYSON PEAK - Page 37

FORT ASSEMBLY
STEP 13
086 (x78)
SCREW - 1 1/2"
DOUBLE ROCK -
SUB ASSEMBLY
RIGHT ROCK -
SUB ASSEMBLY
DOUBLE ROCK -
SUB ASSEMBLY
LEFT ROCK -
SUB ASSEMBLY
DOUBLE ROCK -
SUB ASSEMBLY
RIGHT ROCK -
SUB ASSEMBLY
M1 (x1)
ROCK WALL BOARD
M1 (x2)
ROCK WALL BOARD
M1 (x2)
ROCK WALL BOARD
M1 (x2)
ROCK WALL BOARD
ROCK WALL BOARD - W4L13758
5/8"x3 3/8"x48 7/8" (16x86x1243)
M1
(x7)
LEFT ROCK - SUB ASSEMBLY (x1)
(FROM STEP 14).
RIGHT ROCK - SUB ASSEMBLY (x2)
(FROM STEP 14).
DOUBLE ROCK - SUB ASSEMBLY (x3)
(FROM STEP 14).
SCREW PFH
8x1 1/2
(x78)
H100086
37
