Backyard Discovery GRAYSON PEAK - Page 61

FORT ASSEMBLY
STEP 36
TWIST GROUND STAKE INTO
THE GROUND WHERE SHOWN.
THEN USING GROUND STAKE
AS A GUIDE, DRILL A 7/16" (10mm)
HOLE FOR HARDWARE.
GROUND STAKE LOCATIONS
REPEAT ON OPPOSITE SIDE.
004 (x2)
NUT BARREL - 5/8"
031 (x2)
WASHER - 12x19
008 (x2)
BOLT - 5/16x1"
009 (x1)
BOLT - 1 1/4"
031 (x1)
WASHER - 12x19
005 (x1)
NUT BARREL - 7/8"
004 (x4)
NUT BARREL - 5/8"
031 (x4)
WASHER - 12x19
222 (x4)
BOLT - 3/4"
178 (x7)
AUGER GROUND STAKE
AUGER GROUND STAKE
(x7)
A100178
BOLT WH
5/16x3/4
(x4)
H100222
BOLT WH
5/16x1 1/4
(x1)
H100009
BOLT WH
5/16x1
(x2)
H100008
WASHER LOCK
EXT
12x19
(7)
H100031
NUT BARREL WH
5/16 x 5/8
(x6)
H100004
NUT BARREL WH
5/16x7/8
(x1)
H100005
