Backyard Discovery Highlander 6010 - General Information; Safe Play Area

PAGE 9 - SAFE PLAY AREA
Dimensions:
• The Highlander has One layout option.
Layout: Ground Dimension Safe Play Area*
14’-8 ½” x 15’-10 ½’’ x 12’-10” high 26’-8 ½” x 33’-6 ½” x 18’-10” high
*Level Ground Surface - See below
• Additional accessories may increase the size of the Safe Play Area.
• Max fall height 91 ½"
General Information:
Your set has been designed and engineered for children
only and for residential use only.
A maximum of 150 lbs. per child is recommended for
play activities designed for individual use.
A maximum of 120 lbs. per child is recommended for
play activities designed for multiple child use.
A maximum of 9 children is recommended for this unit.
set.
Back
Right
Left
Front
14'-8 1/2"
15'-10 1/2"
26'-8 1/2"
33'-6 1/2"
18 1/4
96
114 3/4
28 7/16
28 1/2
67 7/8
61 7/8
14
27 3/4
89 1/4
24
