Backyard Discovery HILLCREST - Page 11

Owner's Manual - Parts Identification
Accessory Components (Not to Scale)
SLIDE RAIL 10'
BOTTOM RIGHT
GREEN
(x1)
A6P00484
SLIDE RAIL 10'
BOTTOM LEFT
GREEN
(x1)
A6P00483
SLIDE RAIL 10'
TOP RIGHT
GREEN
(x1)
A6P00486
SLIDE RAIL 10'
TOP LEFT
GREEN
(x1)
A6P00485
L BRACKET
2.5x38x55x55
(x3)
A4M01046
L BRACKET
66x66x127
(x2)
A100140
"A" REVISION
TAG
(x1)
A100314
GROUND STAKE
REBAR
(x2)
A4M00527
HAND GRIP
METAL GREEN
381 c/c
(x4)
A100118
SLIDE BED 10' LIGHT GREEN
(x1)
A100035
SLIDE TUBE SUPPORT
(x4)
A6P00487
AUGER GROUND
STAKE
(x6)
A100178
PICKET PAL
(x1)
A6P00410
