Backyard Discovery HILLCREST - Page 10

Owner's Manual - Parts Identification
Hardware Components
BOLT HEX
5/16x1 1/4
(x4)
H100042
BOLT HEX
5/16x4 1/4
(x2)
H100054
BOLT PTH
1/4x3/4
(x26)
H100063
SCREW PWH
8x3/4
(x22)
H100070
SCREW PFH
8x1 1/2
(x282)
H100086
SCREW PFH
8x1 1/8
(x305)
H100088
SCREW PFH
8x1 3/4
(x65)
H100089
SCREW PFH
8x2 1/2"
(x73)
H100090
SCREW PFH
8X2 1/4
(x26)
H100091
WASHER SPLIT
5/16
(x4)
H100095
WASHER FLAT
11x25
(x13)
H100102
WASHER FLAT
8x27
(x9)
H100105
NUT LOCK
5/16
(x2)
H100110
SCREW PFH
8x2
(x7)
H100111
SCREW PFH
8 x 1/2
(x4)
H100124
SCREW PWH
8x5/8
(x2)
H100128
WASHER LOCK EXT
6x15
(x9)
H100138
LAG SCREW WH
1/4x2
(x9)
H100146
BOLT HEX
3/8x5-1/2
(x13)
H100654
WASHER LOCK INT
10x18
(x13)
H100107
WASHER LOCK EXT
12x19
(x12)
H100031
WASHER LOCK INT
8x15
(x26)
H100108
WASHER LOCK EXT
8x19
(x155)
H100030
TORX BIT
T-40
(x1)
A100042
TORX WRENCH
T-40
(x1)
A100041
TORX BIT
T-30
(x1)
H100147
TORX WRENCH
T-30
(x1)
H100114
SCREW SETTER
(x1)
H100764
MAGNETIC DRIVER
(x1)
H101100
