Backyard Discovery HILLCREST - Page 9

Owner's Manual - Parts Identification
NUT BARREL WH
5/16 x 5/8
(x9)
H100004
NUT BARREL WH
5/16x7/8
(x9)
H100005
NUT BARREL WH
5/16x1 1/2
(x9)
H100006
BOLT WH
5/16x1
(x6)
H100008
BOLT WH
5/16x1 1/4
(x20)
H100009
BOLT WH
5/16x1-1/2
(x11)
H100010
BOLT WH
5/16x1 3/4
(x4)
H100011
BOLT WH
5/16x2
(x25)
H100012
BOLT WH
5/16x2 1/4
(x30)
H100013
BOLT WH
5/16x2 3/4
(x2)
H100015
BOLT WH
5/16x3
(x14)
H100016
BOLT WH
5/16x3 1/4
(x13)
H100017
BOLT WH
5/16x3 1/2
(x2)
H100018
T-NUT
1/4
(x26)
H100072
T-NUT
3/8
(x13)
H100073
T-NUT
5/16
(x124)
H100074
BOLT WH
5/16x1/2
(x25)
H100115
BOLT WH
5/16x4-1/4
(x4)
H100166
BOLT WH
5/16x3/4
(x4)
H100222
BOLT WH
5/16x4 3/4
(x2)
H100505
LAG SCREW WH
5/16x2 1/2
(x52)
H100028
LAG SCREW WH
5/16x2
(x7)
H100027
9
