STEP 7 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
4
H100013
BOLT WH 5/16x2 1/4
4 H100030 WASHER LOCK EXT 8x19
4
H100074
T-NUT 5/16
4 H100138 WASHER LOCK EXT 6x15
4
H100146
LAG SCREW WH 1/4x2
DECK BRACE - W4L16002
1 3/8"x3 3/8"x15 1/2" (36x86x394)
E04
(x4)
TIP:
INSTALL T-NUTS IN WOOD FIRST
138 (x4)
WASHER - 6x15
146 (x4)
LAG SCREW - 2"
074 (x4)
T-NUT - 5/16"
030 (x4)
WASHER - 8x19
013 (x4)
BOLT - 2 1/4"
E04 (x4)
T-NUT OUTWARD
THIS LOCATION ONLY
