STEP 8 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
24
H100090
SCREW PFH 8x2 1/2
2 H100128 SCREW PWH 8x5/8
FLOOR JOIST - W4L16032
1"x3 3/8"x35 3/4" (24x86x908)
H09
(x2)
FLOOR JOIST - W4L16023
1"x3 3/8"x45 1/2" (24x86x1156)
H01
(x2)
FLOOR JOIST - W4L16026
1"x3 3/8"x40 1/8" (24x86x1018)
H03
(x2)
"A" REVISION TAG
(x1)
A100314
H01 (x2)
H03 (x2)
H09 (x2)
090 (x24)
SCREW - 2 1/2"
128 (x2)
SCREW - 5/8
314 (x1)
"A" REVISION TAG
