Backyard Discovery HILLCREST - Page 38

STEP 9 - FORT ASSEMBLY
SEAT UPRIGHT - W4L16027
1"x3 3/8"x19" (24x86x482)
H04
(x2)
TIP:
INSTALL T-NUTS IN WOOD FIRST
H04 (x2)
010 (x4)
BOLT - 1 1/2"
030 (x4)
WASHER - 8x19
074 (x4)
T-NUT - 5/16"
QTY
PART NUMBER
DESCRIPTION
4
H100010
BOLT WH 5/16x1 1/2
4 H100030 WASHER LOCK EXT 8x19
4
H100074
T-NUT 5/16
