STEP 14 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
6 H100012
BOLT WH 5/16x2
6 H100030 WASHER LOCK EXT 8x19
6 H100074
T-NUT 5/16
WALL RAIL - W4L16047
5/8"x3 3/8"x40 1/8" (16x86x1018)
M11
(x1)
WALL RAIL - W4L16067
5/8"x3 3/8"x45 1/2" (16x86x1156)
M06
(x2)
TIP:
INSTALL T-NUTS IN WOOD FIRST
M11 (x1)
M06 (x1)
M06 (x1)
012 (x6)
BOLT - 2"
030 (x6)
WASHER - 8x19
074 (x6)
T-NUT - 5/16"
