STEP 15 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
1
H100012
BOLT WH 5/16x2
2 H100027 LAG SCREW WH 5/16x2
3 H100030
WASHER LOCK EXT 8x19
1 H100074 T-NUT 5/16
WALL RAIL - W4L16066
5/8"x3 3/8"x49" (16x86x1244)
M05
(x1)
WALL RAIL - W4L16053
5/8"x3 3/8"x16 7/8" (16x86x430)
M18
(x1)
M05 (x1)
M18 (x1)
027 (x2)
LAG SCREW - 2"
030 (x2)
WASHER - 8x19
012 (x1)
BOLT - 2"
030 (x1)
WASHER - 8x19
074 (x1)
T-NUT - 5/16"
