Backyard Discovery HILLCREST - Page 6

Wood Components (Not to Scale)
Owner's Manual - Parts Identification
GABLE BOARD - W4L16065
5/8"x3 3/8"x44" (16x86x1118)
M04
(x2)
WALL RAIL - W4L16067
5/8"x3 3/8"x45 1/2" (16x86x1156)
M06
(x2)
WALL CAP - W4L16068
5/8"x3 3/8"x40 7/8" (16x86x1038)
M07
(x2)
GABLE BOARD - W4L16051
5/8"x3 3/8"x19" (16x86x482)
M15
(x2)
PICNIC SEAT SUPPORT - W4L16050
5/8"x3 3/8"x22" (16x86x558)
M14
(x2)
WALL BOARD - W4L16052
5/8"x3 3/8"x21" (16x86x532)
M16
(x2)
WALL RAIL - W4L16047
5/8"x3 3/8"x40 1/8" (16x86x1018)
M11
(x1)
WALL BOARD - W4L16044
5/8"x3 3/8"x35" (16x86x888)
M10
(x1)
WINDOW TRIM - W4L16048
5/8"x3 3/8"x31 1/2" (16x86x800)
M12
(x1)
WALL RAIL - W4L16053
5/8"x3 3/8"x16 7/8" (16x86x430)
M18
(x1)
FLOOR BOARD - W4L16063
5/8"x3 3/8"x50 7/8" (16x86x1292)
M03
(x20)
WALL RAIL - W4L16066
5/8"x3 3/8"x49" (16x86x1244)
M05
(x3)
WALL BOARD - W4L16074
5/8"x3 3/8"x41" (16x86x1040)
M08
(x9)
WALL BOARD - W4L16075
5/8"x3 3/8"x32" (16x86x812)
M09
(x6)
WALL BOARD - W4L16049
5/8"x3 3/8"x24" (16x86x610)
M13
(x7)
GABLE BOARD - W4L16054
5/8"x3 3/8"x15 1/4" (16x86x387)
M19
(x4)
WALL BOARD - W4L16090
5/8"x3 3/8"x41" (16x86x1040)
M17
(x2)
