Backyard Discovery HILLCREST - Page 67

2 5/8 in
[67 mm]
TYPICAL SPACING
1 3/8 in
[34 mm]
STEP 38 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
24
H100088
SCREW PFH 8x1-1/8"
BOTTOM WALL BOARD - W4L16062
5/8"x3 3/8"x21 3/8" (16x86x544)
M27
(x6)
088 (x24)
SCREW - 1 1/8"
M27 (x6)
SIDE VIEW
67
