Backyard Discovery HILLCREST - Page 68

2 7/8" TYPICAL SPACING
[71 mm]
1 3/8 in
[34 mm]
STEP 39 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
28 H100088
SCREW PFH 8x1-1/8"
BOTTOM WALL BOARD - W4L16062
5/8"x3 3/8"x21 3/8" (16x86x544)
M27
(x7)
SIDE VIEW
088 (x28)
SCREW - 1 1/8"
M27 (x7)
68
